SO RF flange 6 inch DN 150 Class900 slip on flange

Group Steel Pipe Flange ASME B 16.5
Min. Order 200 piece
Terms of Payment L/C, D/A, D/P, Western Union, MoneyGram, T/T, Paypal, Crash
Update Time 2019-10-16
Item specifics
Surface treatmentAnti-rust Oil
SealRaised face Flat face
Connectionwelding
SO RF flange 6 inch DN 150 Class900 Slip on flange

Stock of JS FITTINGS SO flanges

JS FITTINGS manufactures slip on pipe flanges in all steel material grades, including carbon steel slip on pipe flanges, stainless steel slip on pipe flanges and alloy slip on pipe flanges. And carbon steel ASTM A105 is the main material. JS FITTINGS also has some slip on pipe flanges in stock and ready to ship.


Markets of different kinds of surface
1. The yellow painting is bright and dazzling, it is needed in the markets of South East of Asia and Africa.
2. Black painting is looks more seriously than other color, it is needed in the markets of South east and mild east of Asia.
3. Anti-rust oil is popular in the most markets of the world, and it's the cheapest treatment way.
Specification of ASME B16.5 Flanges
Size
1/2"-80"
Pressure
Class150/300/600/9001500/2500
Material
Carbon steel: A105, A105N Q235, 16Mn
Stainless steel: A182 F304, A182 304L, A182 F316, A182 F316L, A182 F51 etc
Standard
ANSI B16.5
Connection Type
Welding
Technology
Forged Machine  CNC Machinery Equipment
Surface Treatment
usually Black painting for A105 carbon steel;
usually Bare for Stainless steel.
Suitable Medium
water, oil, petroleum, gas, chemical, power, metallurgy, shipbuilding, construction etc.
Certificate
Mill test Certificate per EN10204/3.1 and EN10204 /3.2 is also available.
Certification
ISO 9001:2008 Quantity System.
Quality
First-class with finest workmanship.
Packing
Plastic bags, Carton, Plywood cases, pallets, or as per your request.
Delivery Time
5-30 days after the placement of the order according to your quantity.
Port of delivery
Xingang port, Shanghai port, Qingdao Port, others can be negotiated
Payment
T/T, L/C, all can be negotiated
Other
Special design available according to your requirements.
Loading of WN Flanges
